By
Genelec
Genelec 8040B Active Monitoring System
Write a Review
Genelec 8040B Active Monitoring System
Part #:
8040BPM
Model #:
8040B
Availability:
Usually arrives in 5-9 business days.
Please be aware that global supply shortages outside our control may interfere with our normal delivery times and product availability. For more information, email sales@proacoustics.com or call us at 888-256-4112.
Certified Audio Expertise
FREE Custom System Design
Get Expert Help Fast
Description
The Genelec 8040B studio monitor produces high SPL, low colouration and broad bandwidth in a modest enclosure. It contains drivers, matched power amplifiers, active crossover and protection circuitry. The 8040 Minimum Diffraction Enclosure (MDE™) and advanced Directivity Control Waveguide (DCW™) technologies provide superior frequency balance and neutral sound imaging in all production environments. 8040B features Genelec Intelligent Signal Sensing (ISS™) circuitry which switches the monitor to standby when no audio input is detected (ErP 2013 Directive).
Its superior performance makes it ideal for many applications, such as music studios, post-production facilities, mobile vans, radio and TV broadcasting.
Features
- 6.5" Woofer, 3/4" Tweeter
- 90W Bass Amplifier, 90W Treble Amplifier
- Auto Switching to Standby Saves Power
- Curved Edges Reduce Distortions
- Wide On and Off Axis Response
- Die-Cast Aluminum Enclosure
- Iso-Pod Table Stand Reduces Vibration
Specifications
| Lower Cut-Off Frequency, -3 dB | ≤ 45 Hz |
|---|---|
| Upper Cut-Off Frequency, -3 dB | ≥ 20 kHz |
| Free Field Frequency Response | 48 Hz - 20 kHz |
| Maximum Peak Acoustic Output Per Pair | ≥ 115 dB SPL |
| Self Generated Noise Level | ≤ 10 dB |
| Harmonic Distortion at 90 dB SPL | 50...100 Hz < 2 % > 100 Hz < 0.5 % |
| Drivers | 6.5" (165 mm) cone 0.75" (19 mm) metal dome |
| Dimensions (H x W x D) | 13.81" (350 mm) x 9.38" (237 mm) x 8.81" (223 mm) |
| Weight | 20.7 lbs (9.4 kg) |
